WOODWORKING MACHINE DOUBLE SIDE PLANER,DOUBLE SIDE MOULDER

Model: MBX206F

Category: Woodworking Machinery Industry / Planing & Moulding Machinery / Double Surface Planer

Online Inquiry

Characteristics

Shandong Baishengyuan Co.,Ltd.
Automatic Double side moulder, (automatic double side planer).
ModelS: MBX204F; MBX206F
Max. Planing width (mm): 430; 610
Max planing thickness (mm): 120; 170
Min planing thickness (mm) 10
Min. Planing length (mm): 260; 320
Max. Planing capacity of upper tool axle per time (mm): 5
Max. Planing capacity of lower tool axle per time (mm): 5; 3
Feed speed (stepless speed changing)(m/min): 4-16; 4.1-19.5
Spindle speed of upper and lower tool axles (rpm): 5600; 4500
Cutting speed of upper and lower tool axles (m/s): 22; 27
Cuttig diameter of upper and lower tool axles (mm): 101; 125

Lift speed of thicknesser (mm/min) 100; 90
Upper tool axle motor power (kw) 7.5; 11
Lower tool axle motor power (kw) 5.5; 7.5
Feed motor power (kw): 1.5; 2.2
Lift motor power (kw): 0.37;
Overall dimensions (mm): 2350*900*1700; 2554*1117*1677
Weight (kg): 2500; 3200
Class: New
