3 ply, 5 ply, 7 ply Computer-Controlled High-Speed wide breadth corrugated cardboard production line
Model: West River
Category: Automatic/Industrial Machines & Equipments / Paper Making & Converting Machines / Corrugated Cardboard Making Machines
Characteristics
The 3ply, 5ply, 7ply and multi-function corrugated cardboard production line mainly consist of the following equipments: Mill roll stand, Pre-conditioner, Pre-heater, Auto-splicer, Single facer, Conveying span bridge, Multi-ply Pre-heater, Glue application machine, Double facer, Slitter scorer, Cut-off, Conveyer and Stacker, Glue making system, and Electric control system etc.
Specifications
Brief Introduction of the Working Procedure
Feed the paper roll into the Mill Roll Stand. In the Pre-heater, the paper roll is heated and its moisture and tension force are adjusted. The paper roll is pressed to a corrugated shape and fed with glue in the Single Facer, and then it is agglutinated to the Multi-ply Pre-heater for the second pre-heat. The Glue Application machine puts glue on the sharp top of the single face corrugated cardboard before it is heating agglutinated with another paper roll in the Double Facer. After cooling formed in the Double Facer, a piece of corrugated cardboard is made. According to the requirement of the order, the corrugated cardboard is cut precisely in the Slitter Scorer and the Cut-off. A piece of rectangle corrugated cardboard is finished. After quantity counts and being piled up in the Stacker, the finished cardboard can be conveyed out. An entire working procedure of the production line is completed.
Paper output speed varies from 100m/min – 300m/min
Valid Breadth：1200mm - 2800mm
Total length between：65m -130m
