Specifications

Structure and performance characteristics

The machine itself has sufficient rigidity, can carry heavy cutting work

The machine has enough power and a wide range of speed, can give full play to the effectiveness of the tool, and can use carbide cutting tools for high-speed cutting

Spindle speed impulse device, easy to speed

Specification :

Table size : 1320×320

Table T-slot (slot number x width x pitch) :3-18-70

Maximum table load : 500kg

X direction (vertical) manual/auto : 700/680

Y to(slide seat horizontal) manual/auto : 255/240

Z direction (vertical)manual/auto : 320/300

Cutting feed speed : X.Y:23.5-1180 Z:8-394

Rapid moving speed : X:2300 Y:2300 Z:770

Spindle speed range : 30-1500

Spindle speed step : 18

Swivel angle of table : 45°

Distance from spindle center to table : 30-350

Spindle power : 7.5KW

Dimensions : 2294×1770×1665

Machine weight : 2650
