New horizontal saw machine,GB4235X angle cut 45°,60° band saw machine for metal cutting,metal band sawing machine,
Model: GB4235X
Category: Machine Tools / Sawing Machines / Band Saws, Horizontal Type
Characteristics
GOLD CNC provides angle metal band saw machine for you.
The structure of the sawing machine is a double column.
The saw machine series can be divided into: numerical control series, ordinary double column series, ordinary Longmen line rail series and corner series.
The model of Angle saw machine is divided into: GB4228X/4230X/4235X/4240X/4250X/4260X.
Specifications
New horizontal saw machine,GB4235X angle cut 45°,60° band saw machine for metal cutting,metal band sawing machine,
GOLD CNC provides angle metal band saw machine for you.
The structure of the sawing machine is a double column.
The saw machine series can be divided into: numerical control series, ordinary double column series, ordinary Longmen line rail series and corner series.
The model of Angle saw machine is divided into: GB4228X/4230X/4235X/4240X/4250X/4260X.
Specifications GB4235X
Max.cutting(mm) 0° 350W×350H ,
45° 270W×270H,
60° 120W×120H
Saw blade speed(m/min) 27、45、69
Saw blade size(mm))34×1.1×4515
Main motor(kw) 4
Hydraulic motor(kw)0.55
Main transmission structure Worm gear transmission
Band saw blade tensioning method Manual
Working clamping mode Hydraulic vice
Cleaning wire brush & flood coolant
Cooling motor power(kw) 0.04
Dimensions(mm)2000×1300×1700
