Auto-cable Sandpaper Abrasion Resisance Tester
Model: ST-6604
Category: Automatic/Industrial Machines & Equipments / Testing Equipment / Inspecting/Measuring Instrument and Parts
Characteristics
ISO 6722 Abrasion Resistance Tester, JASO D618 Abrasion Testing, SAE J 1127 &1128 Abrasion Tester
Specifications
ST-6604 Auto-cables Sandpaper Abrasion Resistance Tester
Standards: According to ISO 6722-2011, QC/T 730-2005, JASO D618-2008, JASO D608-92, JASO D611-94, SAE J1127, SAE J1128, JIS C3406 etc.
Used range: Applied to test the resistance to abrasion of Auto cable insulation jacket in moving condition.
Technical parameters:
1. Sectional area of sample: 0.13~8mm2.
2. Weight of the bracket, support rod, and pivoting arm total weight of 0.63N;
3. Material of sandpaper: 150J P150, 180J, 80J as request to make.
4. Speed of sandpaper: 1500mm/min as a constant speed for moving
5. Angle of sandpaper: approach and exit the test sample from below at an angle of 29 degree.
6. Diameter of supporting pin: ф6.9±0.1mm.
7. Length of measuring sandpaper: 0-99999.9mm can be preset and resolution is 0.1mm
8. Weights: as difference request to make
10. Radian of support rod groove: R114mm, depth of grooves are 0.5mm, 1mm and 2mm total of 3 kinds of size
