Portable Regular.Irreglar Chamfeing Machine
Model: JT-100C.JT-100R
Category: Machine Tools / Others / Other Machinery
Characteristics
A. Adopt with flat face mill cutting. In order to save the cutter costs.
B. Available for 2 functions adjusting. The original for L type chamfering (Fig 1);
The new for V type chamfering (Fig 2).
C. For V type chamfering: save energy. Also the surface of workpeice will be more
smoothly After chamfered.
Specifications
MODEL:JT-100C.100R.100C+R
Capacity, Original-L Model:0~3m/m
Capacity, New-V Model:0~5m/m (2 times processing)
Speed:11000r.p.m
Option speed:Variable speed, 2800~11000r.p.m
Table size:100×70mm
Length of guide rails:D100×ψ28×6mm
Motor:100V~240V,50/60Hz,1PH
Non Load Motot:670W 6.0A
Weight:2.4KGS/ 2.8KGS
Packing 38×13×14cm
Measurement 0.24Square feet
