Specifications



CHARACTERISTIC AUTOMATIC CUTTING&SEWING
SERVO MOTOR 　 2.0kw x1 1.0KWx1 JAPAN
SUCCESSIVE CUTTING 　HEAT SUCCESSIVE CUTTING
SEWING MACHINE (DKN-3BP) 1PCS
LAMINATED CUTTING 1PCS
APPLICABLE PLASTIC CLOTH PP/PE WOVEN BAGS
PRODUCTION CAPACITY 40~45pcs(BAG/MIN)
CUTTING LENGTH 550~1250 MM
CUTTING WIDTH 400~850 MM
CUTTING ACCURACY +.- 1MM
BAG MOUTH ANTI-STUCK DEVICE EQUIPPED
STITCHING RANGE 3.8~8 (P/MM)
DIAMETER OF UNWINDING CLOTH 1200 MM
SIDE FOLDING WIDTH 15~25MM
人力 MAN POWER 1 PERSONS
MAIN DRIVING MOTOR AC 2HP
POWER REQUIRED 14.2KW
AIR COMPRESSOR 3HP X 1UNIT
DELIVERY UNIT COUNTING STACK TYPE BELT CONVEYOR
MACHINE DIMENSION L7980 x W3880 x H1360MM (N.W 2800KGS)
CUBAGE ARK 1X20"
