ARMLESS TYPE TOOL MAGAZINE
Model: LV
Category: Machine Tools / Machining Centers / Machining Centers, Vertical
Characteristics
◆ The exclusive use of the SANJET ball type indexing mechanism enables a machine tool to perform tool change smoothly and stably.
◆ SANJET unique one-piece constructed tool gripper design allows strong tool holding and prevents deformation of the tool disk.
◆ SANJET unique one-piece constructed tool gripper can be installed easily by means of only one bolt.
Specifications
| Magazine Specification | 30# | 40# | 50# |
| Tool Specification | BT/CAT/DIN/ISO/HSK A series/HSK E series | ||
| Tool loading capacity | 8/12/16/20/24 | 8/12/16/20/24 | 16/20 |
| Max. tool length | 250mm | 350mm | 400mm |
| Max. tool diameter full tool | φ50mm | φ100mm | φ145mm |
| Max tool weight | 3kg | 8kg | 16kg |
| Tool indexing time | 0.7sec/50HZ ; 0.6sec/60HZ | 0.7sec/50HZ ; 0.6sec/60HZ | 1sec/50HZ ; 0.9sec/60HZ |
| Tool selection | Shortest route tool selection | ||
| Driving voltage | 3φ 220V/380V | ||
| Air source pressure | 5kg/cm2 | ||
