CHAIN GRIPPER TYPE TOOL MAGAZINE WITH ARM
Model: DVCA
Category: Machine Tools / Machining Centers / Vertical Machining Centers, Double-Column-Type
Characteristics
• Modular design of tool magazine and tool running component can be replaced and customized according to customers’ needs.
• System integration without additional tool changing PLC editing requirement.
• With I/O communication, it can be used with any brand of controller and system.
Specifications
| Tool loading capacity | 60T/120T |
| Tool Specification | HSKA63 |
| Max. tool length | 300mm |
| Max. tool diameter full tool | φ75mm |
| Max. tool weight | 8kg |
| Magazine drive | Servo motor |
| Tool selection | Random tool selection |
