CHAIN GRIPPER TYPE TOOL MAGAZINE
Model: DVC
Category: Machine Tools / Machining Centers / Vertical Machining Centers, Double-Column-Type
Characteristics
◆ Exclusively designed connection between the tool chain and the tool gripper provides extreme smoothness and stability for the tool chain running.
◆ Exclusively using high precision and low backlash reducer in combination with rearmount servo motor drive that ensures uniform gravity distribution and convenient for motor replacement.
Specifications
| Magazine Specification | 30# | 40# | 50# |
| Tool Specification | BT/CAT/DIN/E40/ISO25 | BT/CAT/DIN/HSKA63 | BT/CAT/DIN |
| Tool loading capacity | 24/32/48/60 | 24/30/32/48/60 | 16/24/32/40 |
| Max. tool length | 200mm | 350mm | 140mm |
| Max. tool diameter full tool | φ80mm | φ78mm | φ125mm |
| Max tool weight | 3kg | 8kg | 15kg |
| Tool chain drive method | Servo drive | Servo motor | Servo motor |
