SYSTEM DRUM TYPE TOOL MAGAZINE
Model: DKSS
Category: Machine Tools / Machining Centers / Machining Centers, Vertical
Characteristics
◆ Unique acceleration and deceleration of the S-curve control, the arm is rotated to the buckle tool, the spindle impact to a minimum, effectively protect the spindle and prolong life.
◆ When using a tool with more than 4KG, follow the heavy tool mode instructions to ensure tool change stability.
◆ Global Initiative Hand Crank Reducer. Exclusive use of the Sanjet's manual rotating crank for the adjustment of operation mechanism.
DKSS：
◆ Double Servo: Magazine with servo motors can effectively avoid the inertia force caused by the rotation of the tool disk when machining. It affects the machining accuracy of the column vibration.
◆ The integration of two single drive servo motor, using I/O communication, can be any brand of controller and system.
Specifications
| Magazine Specification | 30# | 40# |
| Tool Specification | BT/CAT/DIN/ISO/HSK A series/HSK E series | |
| Tool loading capacity | 16/20/24/30/32 | |
| Max. tool length | 250mm | 350mm |
| Max. tool diameter full tool | φ70mm(16T);φ55mm(20T) φ60mm(24T);φ60mm(30T) φ55mm(32T) |
φ85mm(16T);φ95mm(20T) φ80mm(24T);φ75mm(30T) φ75mm(32T) |
| Max. tool weight | 3kg | 8kg |
| Tool change time (T to T) (Tool clamp or unclamp time is 0.5 sec) |
1.2sec | 1.3sec |
| Tool selection | Shortest route tool selection | |
| Magazine motor | DKCS-Brake motor / DKSS-Servo system | |
| Tool indexing time | DKCS、DKSS 0.6sec/60HZ | |
| Driving voltage | 3φ 220V | |
| Air source pressure | 5 kg/cm2 | |
